Express Price: $15,900.00
Power:
Engine : 4-stroke, DOHC, 8-valve parallel-twin, liquid cooled
Displacement : 999cc
Bore x Stroke : 92.0 x 75.1 mm
Compression Ratio : 11.5:1
Maximum Torque : 76.7 lb-ft @ 7000 rpm
Fuel System : DFI with two 50mm throttle bodies
Ignition : TCBI with electronic advance
Starting System : Electric
Transmission : Automatic CVT with centrifugal clutch (H,L,N,R)
Final Drive : Selectable 2WD/4WD with locking front differential, shaft
Engine Braking : Yes
Capability:
Front Suspension / Wheel Travel
Double wishbone, FOX 2.5 PODIUM LSC shocks with piggyback reservoir, fully adjustable preload, and 24-position adjustable compression damping/18.6 in.
Rear Suspension / Wheel Travel
4-link trailing-arm rear suspension, FOX 2.5 PODIUM LSC shocks with piggyback reservoir, fully adjustable preload, and 24-position adjustable compression damping/21.1 in.
Front Tires : MAXXIS Carnivore 31 x 10.00R15 8PR
Rear Tires : MAXXIS Carnivore 31 x 10.00R15 8PR
Steering : Electric Power Steering (EPS) / rack-and-pinion
Front Brakes : Dual hydraulic discs with two-piston calipers
Rear Brakes : Dual hydraulic discs with single-piston calipers
Ground Clearance : 14.2 in (max), 13.6 in (std)
Fuel Capacity : 10.6 gal
Turning Radius : 20.3 ft
Cargo Bed Dimensions (LxWxH) : 14.6 x 33.1 x 9.1 in
Cargo Bed Capacity : 351 lbs
Load Capacity : 781 lbs
Seating Capacity : 2
Towing Capacity : N/A
Lighting : (2) LED headlights, (2) LED taillights, LED stoplight
Details:
Frame : Ladder type, tubular steel
Overall Length : 133.3 in
Overall Width : 68.1 in
Overall Height : 76.6 in
Curb Weight : 2019.8 lbs (2022.0 CA)*
Wheelbase : 98.8 in
Instruments
Multi-function digital meter with bar-style tachometer (2 display options), digital speedometer, bar-style fuel gauge, gear indicator (L, H, N, R), Power Mode, driving mode (2WD/4WD/4WD+Diff Lock) indicator, Economical Riding Indicator, clock, odometer, dual trip meters, hour meter, water temperature, digital battery gauge, bar-style CTV temperature, seatbelt warning lamp, oil warning lamp, engine check lamp, water temperature warning lamp, neutral indicator lamp, reverse indicator lamp, parking indicator lamp, EPS warning lamp, and CVT belt warning lamp.
Wheel Type : Alloy with bead-lock wheels
Color Choices : Fragment Camo Gray
Warranty : 6 months
Kawasaki Protection Plus™ (optional) : 12, 24, or 36 months
Features
| Features - Trim | - |
| Price | Standard |
| Price - Warranty (Months) | 6 |
| Price - Warranty (Condition) | Limited |
| Features - Odometer | 2898 |
| Engine | Standard |
| Engine - Engine Type | Parallel Twin |
| Engine - Cylinders | 2 |
| Engine - Engine Stroke | 4-Stroke |
| Engine - Torque (Ft Lbs) | 76.7 |
| Engine - Torque (Nm) | 104 |
| Engine - Torque RPM | 7000 |
| Engine - Cooling | Liquid |
| Engine - Valves | 4 |
| Engine - Valves Per Cylinder | 2 |
| Engine - Valve Configuration | DOHC |
| Engine - Bore (mm) | 92 |
| Engine - Bore (in) | 3.62 |
| Engine - Stroke (mm) | 75.1 |
| Engine - Stroke (in) | 2.96 |
| Engine - Displacement (cc) | 999 |
| Engine - Displacement (ci) | 60.9 |
| Engine - Compression Ratio | 11.5:1 |
| Engine - Starter | Electric |
| Engine - Fuel Requirements | Regular |
| Engine - Fuel Type | Gas |
| Carburetion | Standard |
| Carburetion - Fuel Injector | Yes |
| Carburetion - Fuel Injector Size (mm) | 50 |
| Carburetion - Carburetor | No |
| Carburetion - Number Of Carburetors | 0 |
| Carburetion - Carburetion Type | Fuel Injected |
| Parental Controls - Speed Governor | No |
| Snorkel Air Intake | Standard |
| Features - Special Price | 0 |
| Transmission | Standard |
| Transmission - Transmission Type | Continuously Variable (CVT) |
| Transmission - Primary Drive (Rear Wheel) | Shaft |
| Transmission - Primary Drive (Engine / Transmission) | Belt |
| Transmission - Reverse | Yes |
| Transmission - Hi / Low Range | Yes |
| Transmission - Primary Drive (Front Wheel) | Shaft |
TECHNICAL SPECIFICATIONS
| Dimensions | Standard |
| Dimensions - Length (in) | 133.3 |
| Dimensions - Length (mm) | 3385.8 |
| Dimensions - Width (in) | 68.1 |
| Dimensions - Width (mm) | 1729.7 |
| Dimensions - Height (in) | 76.6 |
| Dimensions - Height (mm) | 1945.6 |
| Dimensions - Wheelbase (in) | 98.8 |
| Dimensions - Wheelbase (mm) | 2509.5 |
| Dimensions - Turning Radius (ft) | 20.3 |
| Dimensions - Ground Clearance (in) | 13.6 |
| Dimensions - Ground Clearance (mm) | 345.4 |
| Dimensions - Front Tread Width (in) | 59.3 |
| Dimensions - Front Tread Width (mm) | 1505 |
| Dimensions - Rear Tread Width (in) | 59.4 |
| Dimensions - Rear Tread Width (mm) | 1510 |
| Dimensions - Length (ft) | 11.11 |
| Dimensions - Length (ft/ft) | 11 |
| Dimensions - Length (ft/in) | 1.3 |
| Weight | Standard |
| Weight - Wet Weight (lbs) | 2019.8 |
| Weight - Wet Weight (kg) | 916.2 |
| Weight - Payload Capacity (lbs) | 781 |
| Weight - Payload Capacity (kgs) | 354.3 |
| Capacities | Standard |
| Capacities - Fuel Capacity (gal) | 10.6 |
| Capacities - Fuel Capacity (l) | 40.1 |
| Performance | Standard |
EXTERIOR
| Construction | Standard |
| Construction - Frame | Steel |
| Construction - Body Material | Plastic |
| Exterior Guards | Optional |
| Exterior Guards - Chain Guard | No |
| Exterior Guards - Brush Guard | Yes |
| Exterior Guards - Light Guard | Yes |
| Exterior Guards - Rear Mud Guards | Yes |
| Exterior Covers | Standard |
| Exterior Covers - CV Boot Cover | No |
| Nerf Bars | Optional |
| Front Bumper | Optional |
| Rear Bumper | Optional |
| Front Fender Flairs | Optional |
| Rear Fender Flairs | Optional |
| Skid Plate | Optional |
| Skid Plate - A-Arm Skid Plate (Front) | Yes |
| Skid Plate - Bash Plate (Front) | Yes |
| Skid Plate - Full Length Skid Plate | Yes |
| Cab Canopy | Optional |
| Cab Canopy - Cab Canopy Material | Hard |
| Cab Canopy - Camouflage | No |
| Cab Cage | Standard |
| Cab Rollbar | Standard |
| Cab Doors | Optional |
| Cab Doors - Cab Door Material | Soft |
| Cab Doors - Camouflage | No |
| Cab / Bed Divider | Optional |
| Other Exterior | Optional |
SUSPENSION
| Front Suspension | Standard |
| Front Suspension - Front Suspension Type | Independent Double Wishbone |
| Front Suspension - Front Travel (in) | 18.6 |
| Front Suspension - Front Travel (mm) | 472.4 |
| Front Suspension - Front Adjustable Fork Pre-Load | Yes |
| Front Suspension - Front Suspension Brand Name | Fox® Podium |
| Rear Suspension | Standard |
| Rear Suspension - Rear Suspension Type | Independent |
| Rear Suspension - Rear Travel (in) | 21.1 |
| Rear Suspension - Rear Travel (mm) | 535.9 |
| Rear Suspension - Rear Adjustable Shock / Spring Pre-Load | Yes |
| Rear Suspension - Number Rear Shock Absorbers | 2 |
| Rear Suspension - Rear Suspension Brand Name | Fox® Podium |
| Rear Suspension - Rear Stabilizer Bar | Yes |
| Rear Suspension - Adjustment Type | Shock Mounted Adjustment |
| Rear Suspension - Air Adjustable | No |
Features
| Features - Latest Photo Modified Date | 2026-02-20 10:08:02 |
| Wheels | Standard |
| Wheels - Wheels Composition | Aluminum |
| Wheels - Front Tire Diameter (in) | 31 |
| Wheels - Rear Tire Diameter (in) | 31 |
| Tires | Standard |
| Tires - Tire Brand | Maxxis® |
| Tires - Front Tire Width | 10 |
| Tires - Front Wheel Diameter | 15 |
| Tires - Rear Tire Width | 10 |
| Tires - Rear Wheel Diameter | 15 |
| Tires - Front Tire (Full Spec) | Maxxis® Carnivore: 31 x 10.00R15 8PR |
| Tires - Rear Tire (Full Spec) | Maxxis® Carnivore: 31 x 10.00R15 8PR |
BRAKES
| Brakes | Standard |
| Brakes - Front Brake Type | Dual Hydraulic Disc |
| Brakes - Front Brake Diameter (in) | 10.2 |
| Brakes - Front Brake Diameter (mm) | 258 |
| Brakes - Rear Brake Type | Dual Hydraulic Disc |
| Brakes - Rear Brake Diameter (in) | 10.2 |
| Brakes - Rear Brake Diameter (mm) | 258 |
| Engine Braking | Standard |
SEATS
| Seat | Standard |
| Seat - Seat Type | Bucket |
| Seat - Seat Material | Vinyl |
| Seat - Folding | No |
| Seat - Headrest | Yes |
| Seat Specifications | Standard |
| Seat Specifications - Seat Height (in) | 31.1 |
| Seat Specifications - Seat Height (mm) | 790 |
| Seat Specifications - Number Of Seats | 2 |
| Seat Specifications - Number Of Rows | 1 |
| Grab Rail or Strap | Standard |
INSTRUMENTATION
| Digital Instrumentation | Standard |
| Clock | Standard |
| Tachometer | Standard |
| Trip Odometer | Standard |
| Speedometer | Standard |
| Hour Meter | Standard |
| Temperature Warning | Standard |
| Temperature Warning - Temperature Warning Type | Gauge |
| Fuel Level Warning | Standard |
| Fuel Level Warning - Fuel Level Warning Type | Gauge |
| Voltage Meter | Standard |
STORAGE
| Cupholder | Standard |
| Cupholder - Number Of Cupholders | 5 |
| Storage Cover | Optional |
| Storage Cover - Camouflage Trim | No |
| Cargo Bed | Standard |
| Cargo Bed - Bed Length (in) | 14.6 |
| Cargo Bed - Bed Length (mm) | 370.8 |
| Cargo Bed - Bed Height (in) | 9.1 |
| Cargo Bed - Bed Height (mm) | 231.1 |
| Cargo Bed - Bed Width (in) | 33.1 |
| Cargo Bed - Bed Width (mm) | 840.7 |
| Cargo Bed - Bed Capacity (lbs.) | 351 |
| Cargo Bed - Bed Capacity (kgs.) | 159.2 |
| Cargo Bed - Cargo Bed Tilt | Yes |
| Cargo Bed - Cargo Bed Material | Polyethylene |
| Cargo Bed - Integral Tie-Down Hooks | Yes |
| Glove Box / Dash Storage | Standard |
| Cargo Bed Cover - Camouflage Trim | No |
| Cargo Bed Storage | Optional |
| Cargo Bed Storage - Cargo Bed Storage Material | Hard Vinyl |
| Cargo Bed Storage - Cargo Bed Storage Trim | Plain |
LIGHTS
| Work Light Front or Rear | Optional |
| Headlight(s) | Standard |
| Headlight(s) - Type | LED |
GLASS
| Rearview Mirrors | Optional |
| Windshield | Optional |
| Windshield - Height Adjustable | No |
| Windshield - Tinted | No |
| Windshield - Heated | No |
| Windshield - Folding | Yes |
CONVENIENCE
| Power Outlet | Standard |
| Heater | Optional |
| Seat Belts | Optional |
PAINT & FINISH
| Paint | Optional |
| Paint - Primary Color | Camouflage |
| Paint - Secondary Color | Yellow |
| Paint - Metallic | Yes |
AUDIO & COMMUNICATION
| Radio | Optional |
| Radio - Brand Name | Hifonics® |
| Radio - Satellite | No |
| Speakers | Optional |
| Speakers - Number Of Speakers | 2 |
| CD Player - Number Of Discs | 0 |
DRIVE LINE
| Driveline | Standard |
| Driveline - Driveline Type | Selectable 4X2 / 4X4 |
| Driveline - Number Of Driveline Modes | 2 |
| Driveline - Rear Unlocking Differential | Yes |
| Driveline - Rear Solid Axle | No |
| Limited Slip Differential | Standard |
| Limited Slip Differential - Limited Slip Differential Location | Front |
| Differential Lock | Standard |
| Differential Lock - Differential Lock Location | Front |
STEERING
| Steering | Standard |
| Steering - Steering Type | Power |
| Steering - Steering Control | Steering Wheel |
| Tilt Steering | Standard |
TOWING & HAULING
| Rear Hitch | Standard |
| Trailer - Tilt | No |
| Trailer - Removable Tailgate | No |
| Trailer - Removable Sides | No |
| Winch | Optional |
| Winch - Weight (lbs) | 4500 |
| Winch - Weight (kgs) | 2041.2 |
| Winch - Length (ft) | 50 |
| Winch - Winch Brand Name | Warn® |
| Tow Hook | Optional |
| Roller Fairlead | Standard |
MOUNTS
| Windshield Mounts | Optional |
Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
