Capability

Get more done in a day with RANGER 1000. Its purpose-built single overhead cam (SOHC) engine delivers smooth, quiet power and outstanding low speed performance to help you and your crew get the job done.

Ready to Tow

Connect your trailer to the standard 2 in. receiver and maximize the class-leading 2,500 lb. towing capacity for large loads.

Protect the Lawn

For work around the house, use VersaTrac Turf Mode to unlock the rear differential for easier and tighter turns that won't tear up your lawn.

Extend Your Day

All-new LED headlights on Premium models offer enhanced lighting to help start your day earlier and finish later.

Ready to Work

Form meets function with the dash mounted charging port. Conveniently and safely charge your battery so you know your vehicle is ready to work when you are.

Specification:

Engine & Drivetrain

• Cooling - Liquid
• Cylinders Displacement - 999cc
• Drive System Type - High Performance On-Demand True AWD/2WD/VersaTrac Turf Mode
• Engine Braking System (EBS) - Not Equipped
• Engine Type - 4-Stroke Twin Cylinder SOHC
• Fuel System/Battery - Electronic Fuel Injection
• Horsepower - 61 HP
• Transmission/Final Drive - Automatic PVT H/L/N/R/P; Shaft

DIMENSIONS

• Bed Box Dimensions (L x W x H) - 36.75 x 54.25 x 12.5 in (93.3 x 137.8 x 31.75 cm)
• Box Capacity - 1,000 lbs (453.6 kg)
• Estimated Dry Weight - 1,794 lbs (814 kg)
• Fuel Capacity - 11.35 gal (43 L)
• Ground Clearance - 12.5 in (31.8 cm)
• GVW - 3,750 lb (1,700.9 kg)
• Hitch Towing Rating - 2,500 lb (1,134 kg)
• Hitch Type - Standard 2 in (5 cm) Receiver
• Overall Vehicle Size (L x W x H) - 152 x 62.5 x 76 in. (386 x 158 x 193 cm)
• Payload Capacity - 1,750 lb (793.8 kg)
• Person Capacity - 6
• Wheelbase - 113 in (287 cm)
